KTM 250 350 EXC-F SX-F XC-F Starter Motor 79240001000
Brand new aftermarket replacement electric starter motor for compatible KTM-group 250 cc and 350 cc four-stroke applications using OE starter reference 79240001000.
Product Overview
Replacement electric-start motor for motorcycles originally fitted with the 79240001000 starter assembly. Fitment is based on the original starter part number and the specific model/year ranges listed below.
Reference Specifications
- Voltage: 12 V
- Rotation: clockwise
- Drive gear: 9 teeth
- Mounting holes: 2
- Drive gear outside diameter: approximately 12 mm
- Starter type: permanent-magnet direct drive (PMDD) reference specification
Vehicle Compatibility
| Make | Model | Years | Notes |
|---|---|---|---|
| KTM | 250 SX-F Factory Edition | 2015–2026 | Factory Edition variants using 79240001000 |
| KTM | 250 SX-F | 2016–2026 | |
| KTM | 250 XC-F | 2016–2026 | |
| KTM | 250 EXC-F | 2017–2026 | |
| KTM | 250 EXC-F Six Days | 2017–2026 | |
| KTM | 350 SX-F | 2016–2026 | |
| KTM | 350 XC-F | 2016–2026 | |
| KTM | 350 EXC-F | 2017–2026 | |
| KTM | 350 EXC-F Six Days | 2017–2026 | |
| KTM | 350 XCF-W | 2021 | Verified one-year application |
| KTM | Freeride 250 F | 2018–2020 | Also provided as a separate draft listing |
OE / Cross-Reference Numbers
- KTM / Husqvarna / GasGas: 79240001000
- Arrowhead / J&N: 410-58116
- Dirt Racing: 19-0115.DR application reference
Reference numbers are supplied for compatibility identification only. The supplied starter is an aftermarket replacement and is not a Genuine KTM, Husqvarna, GasGas, Arrowhead, J&N or Dirt Racing component unless specifically stated otherwise.
What's Included
- 1 × starter motor assembly as shown in the product photographs
Important Fitment Information
Check the OE number on the original starter before ordering. KTM-group model names can span multiple engine generations, and a 250 or 350 model outside the listed year range may use a different starter.
Compare the mounting points, electrical terminal position, 9-tooth drive gear and starter body with the unit currently fitted. OE parts fiches identify 79240001000 as the complete electric starter motor assembly on the applications listed above.
The starter motor is supplied as the component shown in the photographs. O-rings, starter gears, torque limiter and other surrounding electric-start system parts are separate unless visibly included.
Condition
Brand New
Aftermarket replacement starter motor.
Delivery & Returns
- Free UK delivery with an estimated 2–3 working-day service
- 30-day returns, subject to the item being returned in its original condition
Installation
Disconnect the battery before installation. Starter-system diagnosis and installation should be carried out by a competent motorcycle technician if you are unsure of the cause of the starting fault.
