Yamaha XT660Z Ténéré Rear Brake Pads
New aftermarket rear brake pad set for Yamaha XT660Z and matching XT660ZA Ténéré rear calipers.
Verified rear-pad applications
| Make | Model / variant | Catalogue years |
|---|---|---|
| Yamaha | XT660Z Ténéré | 2008–2016 |
| Yamaha | XT660ZA Ténéré ABS | Selected 2011–2016 |
Check the original rear pad shape when ordering for ABS and different market variants.
Pad shape & interchange references
- EBC: FA208 / FA213 shape family
- SBS: 675
- Ferodo: FDB2005 (replaces FDB2019)
- Brembo: 07BB02
- TRW / Lucas: MCB672
- KTM application references: 90113090000, 50313090000, 54613309200 (depending on model)
- Royal Enfield rear pad application: 594698
These are identification and interchange references only. The supplied pads are unbranded; their precise friction compound and approvals are not specified.
Reference pad dimensions
- Approximate backing-plate width: 78.1 mm
- Approximate backing-plate height: 41.2 mm
- Approximate overall pad thickness: 9.0 mm
- Rear single-caliper application, one pair of pads
Dimensions refer to published FA208/FA213-family equivalents; verify the stock shape against the original pads.
What is included
One rear brake pad set for one caliper (two pads).
Before ordering
Confirm the actual rear caliper, backing-plate outline, retention method and dimensions. Similar model names use different pads across production years; an engine-capacity match alone is not sufficient. The product is an unbranded replacement, not an EBC, SBS or OEM-branded pad set.
Condition
New and unused.
