FA135 Brake Pads for Sinnis Apache Blade Stealth 125
Brand new aftermarket brake-pad set using the FA135 / BPF120 pad pattern. Supplied as one pair for one brake caliper.
Direct Fitment
- Sinnis Apache 125 — front
- Sinnis Apache — QM125GY-2B — FA135-family application; confirm position
- Sinnis Blade 125 — QM125GY (off-road) — front
- Sinnis Stealth 125 — QM125-2D — front left
Pad Cross-References
- EBC: FA135
- Ferodo: FDB497
- DP Brakes: DP411
- SBS: 611
- Vesrah: VD-340
- CMPO: BPF120
- China Parts: BR110004
- OE comparison reference: 100200125
Approximate Pad Dimensions
- Larger pad profile: approximately 96.7–97 mm wide x 42–43 mm high x 7.5 mm thick
- Smaller pad profile: approximately 77–77.5 mm wide x 42 mm high x 7.5 mm thick
- Approximate mounting-pin spacing: 40 mm
- Quantity: 1 pair / 1 caliper set
- Material: Semi-metallic / bimetallic aftermarket friction compound
- SKU: 00558-BRK
Position
Front / Front Left. Follow the individual model/position information in the fitment list above.
Important Fitment Notes
- These Sinnis models are directly listed in the BPF120 / FA135 compatibility catalogue.
Compare the pad shape before ordering. FA135 is used on many unrelated motorcycles, scooters and off-road machines. Model name alone should not override the pad outline, mounting points and dimensions of the original pads.
These pads should be used with a brake disc that is within the motorcycle manufacturer's service specification. Inspect the disc, caliper pins, seals and brake fluid while replacing the pads.
Installation & Safety
Brake components are safety-critical. Clean the caliper, make sure the pads move freely on their pins/guides, torque fasteners correctly and pump the brake lever/pedal until firm before moving the motorcycle. New pads should be bedded in progressively. Professional installation is recommended if you are unsure.
