Honda Cub Chain Case Inspection Cap / Rubber Grommet
Aftermarket replacement chain case inspection / lubrication-hole cap for Honda Cub and other Honda models using the same OE reference family. A useful replacement for a missing, split or hardened drive-chain inspection rubber.
Key Details
- Honda OE / OEM cross-reference: 40545-001-000
- Related Honda references: 40545-141-000, 40545-001-000ZC and 40545-001-000B
- Also described as a chain case cap, chain guard inspection rubber, peephole cap or drive-chain inspection cap
- Designed for an inspection / lubrication opening of approximately 40mm - compare your existing opening before ordering
- Black aftermarket replacement supplied as pictured
Main Listed Fitment
Honda Cub C50, C70 and C90.
Other OE Cross-Reference Applications
Honda parts catalogues use the same 40545-001-000 part-number family on a wider range of machines, including selected CD50, C100, C102, C110, CA100, CA110, Super Cub C125, CA95, CM91, S65, SS125, CT125, ATC90, CA160, CA175 and CA200 models. Some later CG125 chain cases use the related 40545-141-000 reference.
Important: Honda used different chain cases across years and markets. Treat the wider model list as an OE cross-reference guide and compare the cap shape and approximately 40mm opening with your motorcycle before ordering.
Search / Identification Terms
Honda Cub chain case cap, chain guard rubber plug, chain case peephole cap, chain inspection grommet, drive chain inspection cap, 40545-001-000.
